    Rock Drilling Pipe Coupling Sleeve

    Ask Lasest Price
    Brand Name : JCDRILL
    Model Number : H22
    Certification : ISO9001,CE
    Price : 50-300USD/Pcs
    Payment Terms : L/C, T/T
    Supply Ability : 20000set/year
    Delivery Time : Two Week
    • Product Details
    • Company Profile

    Rock Drilling Pipe Coupling Sleeve

    Rock Drilling Tools R32 R38 T38 T45 T51 Half Bridge Threaded Pipe Coupling Sleeve


    Application
    JCDRILL's coupling sleeves are available with both half-bridge and full-bridge types, as well as adapter couplings.
    Semi-bridge coupling, by far is the most popular, has a small non-threaded bridge in the centre. The drill rod cannot thread past the centre of the couplings, and the smaller diameter rods portions butt together in the centre bridge area of the coupling. Semi-bridge couplings are most suited to high torque machines. Most rope (R) and Trapezoidal (T) threaded couplings are semi-bridged.
    Full bridge coupling has a great advantage that it positively eliminates the potential for the coupling to creep along the threaded joints. These couplings, are typically used in a Trapezoidal thread, in surface drilling application, have better uncoupling characteristics and tend to maintain tighter joints. Full-bridge couplings have less chance of jamming and are best suited to machines equipped with independent rotation.
    Adapter couplings are used when changing from one thread type, or size, to another and are typically required only in special circumstances.

    Specification

    Thread model
    Length(mm)
    Panda Part No.
    R22*R22
    140
    R22*140*R22
    R25*R25
    150
    R25*150-R25
    R28*R28
    150
    R28-150-R28
    R32*R32
    150
    R32-150-R32
    R32*R32
    160
    R32-160-R32
    R32*R32
    170
    R32-170-R32
    T38*T38
    170
    T38-170-T38
    T38*T38
    180
    T38-180-T38
    T38*T38
    190
    T38-190-T38
