    Hand Held Pneumatic Jack Hammer , High Impact Energy Air Leg Rock Drill YT29A

    Ask Lasest Price
    Brand Name : JCDRILL
    Model Number : YT29A
    Certification : ISO,CE
    Price : Negotation
    Payment Terms : T/T, L/C, D/P, Western Union, MoneyGram
    Supply Ability : 10000Set/Year
    Delivery Time : In stock
    • Product Details
    • Company Profile

    Hand Held Pneumatic Jack Hammer , High Impact Energy Air Leg Rock Drill YT29A

    Portable Jack Hammer Pneumatic Rock Drill , High Impact Energy Air Leg Rock Drill YT29A


    Application

    YT29A pneumatic rock drill with air leg.

    YT29A Pneumatic Rock Drill is rock drilling equipment with high high impact energy, and lower air

    comsumption,it is widely fitting for coal mine, railway traffic, water conservancy and so on.


    YT29A Pneumatic Rock Drill have water flushing, rifle bar rotation and the pusher leg control is placed

    at the back head of the rock drill. An in line lubricator is included in the delivery of each rock drill.

    Together with the appropriate pusher leg.


    We have a wide range of pusher leg and stopper rock drills to cover all construction, tunneling and mining applications in different rock formations. They are robust but simply designed, with high impact energy and low air consumption.


    This air leg pneumatic Rock Drill is widely used in metallurgy, coal industry, road construction, mining and other drilling operations.

    Characteristics

    1. Easily-accessible position throttle

    2. Integral muffler,lower noise

    3. It accepts heavy duty bits

    4. Reliable structure,easy and stable operation

    5. Drill diam. can be from 32mm-60mm.

    6. Hand-held and air legs rock drill accessible.

    7. Provide the ultimate combination of performance and economy.

    8. Smart,and durable.


    Specification

    YT29A rock drill
    Weight27kg
    Physical size(length*wide*high)659*248*205mm
    Cylinder Diameter82mm
    Piston Structure Stroke60mm
    Working Pressure0.630.50.4Mpa
    Impact Energy≥78≥69≥50J
    Drilling air Consumption≤88≤65≤52L/s
    Drilling Impact Frequency≥39(≥37≥36Hz
    Torque≥20≥17≥15N.m
    Use Hydraulic0.3Mpa
    Air Pipe Diameter25mm
    Water Pipe Diameter13mm
    Appropriate drilling Hole Dia.34~45mm
    Suitable for maximum hole depth5m
    Working Temperature-30~45°C
    Bit Shank SpecificationH22*108±1mm
